3PH-MID600A
with hydraulic outriggers


This CAT-1 backhoe is very compact and
            heavy duty built. All pins have their own
grease fittings.
The backhoe has hydraulic outriggers and uses the hydraulic from the tractor (not the PTO).



   PLAN COST $249 + SHIPPING $20

  Digs down at 7-1/4 ft & lift up to 7 ft.
  Swing 110 degrees
  Bucket Ripping force 2 tons
  Bucket is 11" wide, bucket reach 8 ft.
  Weight approx. 430 pounds
3PH-MID600A  Specifications

Backhoe Plan Overview
      CDP-Backhoe does not have any warranty stated & it is the responsibility of the builder to have all liability for the building
      safety & operation of the machine. We are not responsible for any misprint errors that may occur.
